Place of Origin: | Beijing China |
---|---|
Brand Name: | Lei Mingte |
Certification: | ISO9001:2008 ISO14001:2015 ISO18001:2007 |
Model Number: | Laboratory furniture |
Minimum Order Quantity: | 1 |
Price: | Negotiable |
Packaging Details: | Wooden box |
Delivery Time: | 15 days |
Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
Supply Ability: | 1000 meters |
General Use:: | Commercial Furniture | Type:: | Standard |
---|---|---|---|
Metal Type:: | Cold Rolled Steel Sheet | Place Of Origin:: | Beijing, China |
Brand:: | Leiming | Name:: | Commercial Fume Hood/Fume Hood |
Size:: | 1200/1500/1800*900*2350 | Color:: | Warm White/grey/blue/customized According To Customer Requirements |
Countertop:: | Epoxy Resin/phenolic Resin/stainless Steel/ceramics/physical And Chemical Board/trespa Board/marble, Etc. | Accessories:: | Customer Optional |
Electrical Standard:: | 120-220V, 50/60Hz | ||
High Light: | School Laboratory Fume Hood,1700m3/H Laboratory Fume Hood,1700m3/H Bench Top Fume Hood |
All-Steel Bench-Top Fume Hood Of School Research Institute Laboratory Is Resistant To High Temperature And Acid
Product Description:
product name | School research institute fume hood |
Size | 1200/1500/1800 * 900 * 2350 mm/customized size |
colour | Warm white/grey/blue/customized according to customer requirements |
Framework | Standard 60×40 square steel pipes are sprayed with epoxy powder coating, customers can also put forward other requirements. |
Cabinet | Use cold-rolled steel with a minimum thickness of 1.0mm and coated with a special chemical-resistant epoxy sandblasting powder coating to improve corrosion resistance. |
Countertop | Epoxy resin/phenolic resin/stainless steel/ceramics/physical and chemical board/trespa/marble, etc. |
Lining | From compact lamination. It is a decorative construction board in high temperature and high pressure, waterproof, resistant to moisture, impact, abrasion, acid corrosion, heat resistance, it can prevent the accumulation of pollutants and keep the gas and mist discharge. |
Baffle | Made of compact laminate. Control the direction of air flow to reduce backflow or vortex. |
Window sash | The window sash is made of at least 6mm thick transparent tempered glass, which can slide smoothly in the vertical direction. |
Light | Equipped with no less than 300 Lux 30W fluorescent lamp |
control panel | Used to control the start and stop of the fume hood, the LCD screen, you can manually control the fan, light and volume. |
Annex | Provide faucet and sink, drip stand, eyewash, electric socket, etc. |
Technical data of laboratory fume hood:
1) Opening height of the operating cabinet door: 0-800 mm
2) Face wind speed: 0.4-0 .6 m/s.
3) Noise: <60db
4) Exhaust volume: 1080-1700m3/h
5) Working voltage: AC220V-380V
6) Motor power: 0.09-4kw
Laboratory fume hood ventilation system
The laboratory air supply is carefully designed to meet the designed air exchange rate per hour. Good sash management is essential to balance an efficient laboratory system. The laboratory exhaust is filtered by a carbon HEPA filter module to remove 99.99% of smoke and pollutants. The tubular centrifugal fan is safely pushed away from the building.
